Astro集成Shikijs 和RehypePrettyCode踩坑

Astro集成Shikijs 和RehypePrettyCode踩坑

May 12, 2025
2 min read
大纲

Shikijs重复依赖导致代码报错,打包失败

执行 npm run build 后发生以下错误

npm run build log
src/lib/transformerNotationSkip.ts - error ts(2322): Type 'import("/var/jenkins_home/workspace/dev.2ha.me/node_modules/@shikijs/transformers/node_modules/@shikijs/types/dist/index").ShikiTransformer' is not assignable to type 'import("/var/jenkins_home/workspace/dev.2ha.me/node_modules/@shikijs/types/dist/index").ShikiTransformer'.
  Types of property 'preprocess' are incompatible.

   return createCommentNotationTransformer(
    ~~~~~~

Result (78 files):
- 1 error
- 0 warnings
- 0 hints

检查src/lib/transformerNotationSkip.ts代码

这里引用的ShikiTransformer是/node_modules/@shikijs/types 中的 ShikiTransformer, 与 node_modules/@shikijs/transformers/node_modules/@shikijs/types 中的 ShikiTransformer 代码相同,但是引用不同

TransformerNotationSkipOptions.ts
import { type ShikiTransformer } from '@shikijs/types';
import { createCommentNotationTransformer } from '@shikijs/transformers'

export interface TransformerNotationSkipOptions {
  /**
   * Class for skipped lines
   */
  classActiveSkip?: string
  /**
   * Class added to the root element when the code has skipped lines
   */
  classActivePre?: string
}

export function transformerNotationSkip(
  options: TransformerNotationSkipOptions = {},
): ShikiTransformer {
  const { classActiveSkip = 'skip', classActivePre = undefined } = options

  return createCommentNotationTransformer(
    'skip-lines',
    // comment-start             | marker   | range       | comment-end
    /^\s*(?:\/\/|\/\*|<!--|#)\s+\[!code skip:(\d+):(\d+)\]\s*(?:\*\/|-->)?/,
    function ([_, start, end], _line) {
      _line.children = [{ type: 'text', value: `${start}-${end}` }]
      _line.properties = { style: `counter-set:line ${end}` }

      if (classActiveSkip) this.addClassToHast(_line, classActiveSkip)
      if (classActivePre) this.addClassToHast(this.pre, classActivePre)
      return false
    },
    undefined, // remove empty lines
  )

 }


检查安装好依赖后的@shikijs目录

  • node_modules
    • @shikijs
      • engine-javascript
        • dist
        • README.md
        • package.json
        • LICENSE
      • types
        • dist
        • README.md
        • package.json
        • LICENSE
      • langs
        • dist
        • README.md
        • package.json
        • LICENSE
      • engine-oniguruma
        • dist
        • README.md
        • package.json
        • LICENSE
      • transformers
        • dist
        • README.md
        • package.json
        • node_modules // 重复依赖最外层 node_modules 下的 @shikijs shiki
          • shiki // 与 node_modules/shiki 重复
            • dist
            • README.md
            • package.json
            • LICENSE
          • oniguruma-to-es
            • dist
            • README.md
            • package.json
            • types
            • LICENSE
          • @shikijs // 与 node_modules/@shikijs 重复
            • engine-javascript
            • types
            • engine-oniguruma
            • vscode-textmate
            • core
        • LICENSE
      • themes
        • dist
        • README.md
        • package.json
        • LICENSE
      • vscode-textmate
        • dist
        • README.md
        • package.json
        • LICENSE.md
      • core
        • dist
        • README.md
        • package.json
        • LICENSE

删除node_modules中的重复依赖

shell
rm -rf node_modules/@shikijs/transformers/node_modules/

给Astro博客Markdown代码块添加复制按钮

通过查找Rehype Pretty Code文档找到 Rehype Pretty Code/Copy Button这个实验性功能

1. 安装依赖

shell
npm install @rehype-pretty/transformers

2. 添加transformerCopyButton.ts

这个ts文件是基于node_modules@rehype-pretty\transformers\dist\copy-button.js修改而来

transformerCopyButton.ts
import type { ShikiTransformer } from "shiki";
import { h } from "hastscript";

export interface CopyButtonOptions {
    duration?: number;
    copyIcon?: string;
    successIcon?: string
}

export const transformerCopyButton = (
    options: CopyButtonOptions = {
        duration: 1000
    }
): ShikiTransformer => {
    return {
        name: 'shiki-transformer-copy-button',
        code(node) {
            const button = h('button', {
                class: 'shiki-transformer-button-copy',
                'data-code': this.source,
                onclick: `
                navigator.clipboard.writeText(this.dataset.code);
                this.classList.add('shiki-transformer-button-copied');
                setTimeout(() => this.classList.remove('shiki-transformer-button-copied'), ${options.duration})
                `
            }, [
                h('span', { class: 'ready' }),
                h('span', { class: 'success' })
            ]);
            node.children.push(button)
            node.children.push({
                type: 'element',
                tagName: 'style',
                properties: {},
                children: [
                    {
                        type: 'text',
                        value: buttonStyles({
                            successIcon: options.successIcon,
                            copyIcon: options.copyIcon
                        })
                    }
                ]
            })
        }
    }
}

function buttonStyles({
}: {
    successIcon?: string,
    copyIcon?: string
}) {
    let buttonStyle =
        `
:root {
--border-color: #e2e2e3;
--background-color: #f6f6f7;
--hover-background-color: #ffff
}

pre:has(code) {
    position: relative;
}

pre button.shiki-transformer-button-copy {
    position: absolute;
    top: 12px;
    right: 12px;
    z-index: 3;
    border: 1px solid var(--border-color);
    border-radius: 4px;
    width: 30px;
    height: 30px;
    display: flex;
    justify-content: center;
    place-items: center;
    background-color: var(--background-color);
    cursor: pointer;
    background-repeat: no-repeat;
    transition: var(--border-color) .25s, var(--background-color) .25s, opacity .25s;

    &:hover {
        background-color: var(--hover-background-color);
    }

    & span {
        width: 100%;
        aspect-ratio: 1 / 1;
        background-repeat: no-repeat;
        background-position: center;
        background-size: cover;
    }

    & .ready {
        width: 20px;
        height: 20px;
        background-image: url("${copyIcon}");
    }

    & .success {
        display: none;
        width: 20px;
        height: 20px;
        background-image: url("${successIcon}");
    }

    &.shiki-transformer-button-copied {
        & .success {
            display: block;
        }

        & .ready {
            display: none;
        }
    }
}`
    return buttonStyle
}

3. 添加插件

astro.config.ts
+ import { transformerCopyButton } from './src/lib/transformerCopyButton'

export default defineConfig({
  site: 'https://dev.2ha.me',
  integrations: [
    tailwind({
      applyBaseStyles: false,
    }),
    sitemap(),
    mdx(),
    react(),
    icon(),
  ],
  markdown: {
    syntaxHighlight: false,
    rehypePlugins: [
      [
        rehypeExternalLinks,
        {
          target: '_blank',
          rel: ['nofollow', 'noreferrer', 'noopener'],
        },
      ],
      rehypeHeadingIds,
      [
        rehypeKatex,
        {
          strict: false,
        },
      ],
      sectionize as any,
      [
        rehypePrettyCode,
        {
          theme: {
            light: 'everforest-dark',
            dark: 'everforest-dark',
          },
          transformers: [
            transformerNotationDiff(),
            transformerMetaHighlight(),
            transformerRenderWhitespace(),
            transformerNotationSkip(),
            transformerDiffHighlight(),
+            transformerCopyButton({
+                duration: 1000,
+            })
          ],
        },
      ],
    ],
    remarkPlugins: [remarkToc, remarkMath, remarkEmoji],
  },
  server: {
    port: 1234,
    host: true,
  },
  devToolbar: {
    enabled: false,
  },
})

3. 启动项目后,访问blog后报错

npm run build log
TypeError: Cannot read properties of undefined (reading 'type')
    at /vscodeProjects/dev.2ha.me/node_modules/@shikijs/transformers/dist/index.mjs:516:22
    at Array.flatMap (<anonymous>)
    at /vscodeProjects/dev.2ha.me/node_modules/@shikijs/transformers/dist/index.mjs:507:41
    at Array.forEach (<anonymous>)
    at Object.root (/vscodeProjects/dev.2ha.me/node_modules/@shikijs/transformers/dist/index.mjs:501:21)
    at tokensToHast (/vscodeProjects/dev.2ha.me/node_modules/@shikijs/core/dist/index.mjs:1313:33)
    at codeToHast (/vscodeProjects/dev.2ha.me/node_modules/@shikijs/core/dist/index.mjs:1188:10…

5. 修改node_modules/@shikijs/transformers依赖中的transformerRenderWhitespace方法

node_modules/@shikijs/transformers/dist/index.mjs
function transformerRenderWhitespace(options = {}) {
  const classMap = {
    " ": options.classSpace ?? "space",
    "	": options.classTab ?? "tab"
  };
  const position = options.position ?? "all";
  const keys = Object.keys(classMap);
  return {
    name: "@shikijs/transformers:render-whitespace",
    // We use `root` hook here to ensure it runs after all other transformers
    root(root) {
      const pre = root.children[0];
      const code = pre.children[0];
      code.children.forEach(
        (line) => {
          if (line.type !== "element")
            return;
          const elements = line.children.filter((token) => token.type === "element");
          const last = elements.length - 1;
          line.children = line.children.flatMap((token) => {
            if (token.type !== "element")
              return token;
            const index = elements.indexOf(token);
            if (position === "boundary" && index !== 0 && index !== last)
              return token;
            if (position === "trailing" && index !== last)
              return token;
+            if (token.children.length === 0) {
+              return token;
+            }
            const node = token.children[0];
            if (node.type !== "text" || !node.value)
            return token;
            const parts = splitSpaces(
              node.value.split(/([ \t])/).filter((i) => i.length),
              position === "boundary" && index === last && last !== 0 ? "trailing" : position,
              position !== "trailing"
            );
            if (parts.length <= 1)
              return token;
            return parts.map((part) => {
              const clone = {
                ...token,
                properties: { ...token.properties }
              };
              clone.children = [{ type: "text", value: part }];
              if (keys.includes(part)) {
                this.addClassToHast(clone, classMap[part]);
                delete clone.properties.style;
              }
              return clone;
            });
          });
        }
      );
    }
  };
}
